EN-Neboshchit-GAN-100W-400-700MHz
规格选择
产品简介
Neboshchit GAN-100W PA, GaN tech, 400-700MHz, 100W. Built-in source, -10~55℃. CE/FCC/RoHS. 1Y warranty. MOQ 2pcs.
详细描述
Product Highlights / 产品亮点
- ✅ Precise Frequency Coverage - 400-700MHz professional band, deeply optimized
- ✅ High Power Output - 100W high power, 50±0.5dBm stable output
- ✅ GaN Technology - Gallium Nitride, high efficiency, heat and voltage resistant
- ✅ Built-in Jamming Source - Integrated signal source, customizable frequency
- ✅ Signal Stability - In-band ripple ≤2dB, stable low-loss transmission
- ✅ Cold Start - Reliable startup at -10°C low temperature
- ✅ Certified - CE/FCC/RoHS international certifications
- ✅ Flexible Customization - Frequency, power, and interface customization supported
Technical Specifications / 技术规格
| Category | Parameter | Value |
|---|---|---|
| Basic Info | Model | Neboshchit GAN-100W |
| Series | 400-700MHz Series | |
| Technology | GaN (Gallium Nitride) | |
| RF Parameters | Frequency Range | 400-700MHz |
| Max Output Power | 100W (50±0.5 dBm) | |
| Working Current | ≤6.0-7.0A @ +28V DC | |
| In-band Ripple | ≤2 dB (peak-to-peak) | |
| Custom Frequency | Supported (any 100MHz bandwidth) | |
| Jamming Source | Built-in, customizable frequency | |
| Electrical | Working Voltage | 28V DC (24-32V range) |
| Power Supply | ≥8A @ +28V DC (100W CW output) | |
| Power Interface | Red(+) Black(-) | |
| Enable Control | White wire (High=ON, Low=OFF) | |
| Environment | Operating Temperature | -10°C ~ +55°C |
| Storage Temperature | -40°C ~ +85°C | |
| Gain Stability | ±1.5 dB @ -40°C~+55°C | |
| Power Stability | ±1.5 dB @ -40°C~+55°C | |
| Cold Start | Supported | |
| Mechanical | Dimensions | 138×55×22 mm (excl. connectors) |
| Mounting Holes | 150×65 mm | |
| Weight | 280 g | |
| RF Output Connector | SMA Female | |
| Connector Type | SMA Female | |
| Package Type | Modular Metal Enclosure | |
| Material | Aluminum Alloy | |
| Heat Dissipation | Bottom-mount heatsink | |
| Cooling Requirement | Forced air / Thermal baseplate | |
| Supply Info | Certifications | CE, FCC, RoHS |
| Origin | Shenzhen, China | |
| Warranty | 1 Year | |
| MOQ | 2 Pieces | |
| Lead Time (Stock) | 3-7 Days | |
| Lead Time (Custom) | 15-30 Days | |
| Packaging | PP + Individual Box + Carton |
Bulk Order Discounts / 批量采购优惠
💬 Contact for Quote / 咨询报价
We offer flexible pricing for different order quantities
我们为不同采购数量提供灵活的价格方案
📧 Email: [email protected]
💡 Tip: Larger orders enjoy greater discounts. Contact us for a custom quote.
Product Display / 产品展示
Note: Neboshchit GAN-100W 400-700MHz Jamming Power Amplifier Module
Applications / 应用场景
📡 400-700MHz EW
Electronic Countermeasures
🚁 Anti-UAV
Drone Countermeasure Systems
📻 Comm Jamming
Communication Jamming Systems
🔬 Spectrum Testing
RF Test Equipment
⚔️ Military Training
Simulation Systems
🛡️ Security Systems
Protection Applications
Customization Services / 定制服务
💡 Customization Options
- Frequency Customization: Any 100MHz bandwidth within 400-700MHz range
- Power Customization: 20W / 30W / 50W / 80W / 100W options
- Interface Customization: SMA, N-type, BNC available
- Logo Customization: Silkscreen or laser engraving
- Packaging Customization: Custom box and manual supported
📧 Inquiry: [email protected]
FAQ / 常见问题
Q1: What is the effective jamming range?
A: Effective range depends on target signal strength, antenna gain, and environment. Under standard conditions with a suitable antenna, this 100W module typically achieves 3-8km effective range.
Q2: Does the module require an external jamming source?
A: No. This module has a built-in jamming signal source. A pure amplifier version (no built-in source) is also available on request.
Q3: What applications suit the 400-700MHz band?
A: The 400-700MHz band covers various common communication and UAV control frequencies. Contact us with your specific requirements for professional selection advice.
Q4: What are the cooling requirements?
A: Mount on a metal baseplate for thermal conduction. For continuous 100W output, use forced air cooling to keep the module baseplate below 80°C.
Q5: What customization options are available?
A: Frequency, output power, RF interface, logo, and packaging customization are supported. Frequency customization MOQ is 1 unit.
Q6: What certifications does the product have?
A: CE, FCC, and RoHS international certifications. Certificate copies available on request.
Q7: What is the warranty policy?
A: 1-year warranty covering non-human-caused defects. Free repair or replacement within warranty period. Lifetime technical support provided.
